Overview
Innor’s ATSC iDTV Solution is focus on small LCD panel (size <= 19 inch, resolution <= 1440 x 900) ATSC TV. With our solution, it significantly reduces time to market for customers developing integrated digital TVs for US-HDTV market. The solution brings together all the necessary hardware components and a complete software stack and application that can be customized by customer to meet specific requirements.

Key Features
Provides for Low Cost and Good Performance iDTV
Support Small LCD panel (Size <= 19 inch, resolution <= 1440 x 900)
Receives ATSC/NTSC off air and Clear QAM
Support 256 colors OSD
EPG
Support Close Caption
Parent Control

Hardware Specification
Tuner and Demodulator
ATSC/NTSC 8VSB + Clear QAM64&256

Video
All 18 ATSC input formats are supported
Video output resolution: 480i, 480p, 720p, 1080i, VGA, XGA, 900P

Audio
AC-3 Dolby Digital Audio: 32 ~ 48kHz
MPEG Audio decoding
Dolby Digital 5.1 output(SPDIF)
L/R audio output

MPEG Decoder
MPEG2(MP@ML, MP@HL) video decoder

I/O Interface
Composite/S-Video Input
L/R analog audio output
Serial port

Panel Support
Resolution: 480i ~ 900P
Back Light Control
Gamma Correction
Color Temperature Setting

Software Specification
Includes all functions required by the FCC for US DTVs
Closed Captions: EIA608A & EIA708B
Parental Control
PSIP
VCHIP 2.0
EAS

Multiple languages supported in GUI
English, Spanish, French

Includes a complete setup GUI
Time Zone
Closed captions properties
Picture properties
GUI language selection
Parental control
VCHIP 2.0

Includes a complete navigation GUI
Auto/Manual Channel scan
Channel banner
Channel list
Favorite channel list

EPG
More information, please contact us.
