DESCRIPTION
VP806 is designed by DiB8096P and VP700 is designed by DiB7090P which performs all the
processing form RF signal to MPEG-TS output. VP806 is for ISDB-T/TSB signals and VP700 is for DVB-T signals. VP900 is designed by MN88436(Demod) and MX603(Tuner) which applies to terrestrial digital and cable digital broadcasts. All the modules share same size and same Pins.
FEATURES
VP806 integrates dual bands(VHF and UHF) fully compliant with ABNT NBR-15604 and ARIB STB-b21 specification.
VP700 integrates 3 bands(low-VHF,VHF and UHF) fully compliant with MBRAI specification
VP900 is used for terrestrial digital broadcasting (ATSC) and cable digital broadcasts(Open cable).
Size : 20(W) x 25.5(L) x 2.8(T) mm
RF in, MPEG TS out
I2C interface
High Sensitivity
Power supply：3.3V, 1.8V.
APPLICATIONS
Set-Top Boxes
Portable LCD players
MID
Others TV application for ISDB-T/DVB-T/ATSC demodulation
